Model | ZL60-02 | ||||||||
Working Voltage Range | DC: 12V-24V | ||||||||
Rating Power | 12V: 10-50W/24V: 20-80W | ||||||||
Static Water Head | 2-8 M | ||||||||
Static Flow Rate | 10-45 L/min | ||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000hrs | ||||||||
Working Environment | Liquid: From weak acid to weak base, workable on land (Non-Submergible) | ||||||||
Max Noise | Under normal working status, 1M distance over test instrument <50dB | ||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature ≤100℃ | ||||||||
Application | Electric car engine pump , Vehicle water circulation, Aquarium etc. | ||||||||
Size | IP Grade | Inlet | Outlet | Remarks | |||||
Length(mm） | Width（mm） | Height（mm） | OD
| ID （mm） | OD
| ID （mm） | Inlet and outlet with footgrip | ||
142 | 65 | 104 | IP67 | φ20 | φ14 | φ20 | φ14 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
